K2 MIG 500A 3-PH Feature
Values
Connection voltage 3~, 50/60 Hz
V
400
Operating temperature
oC
-10-+40
Fuse
A
40
Power factor at max current
35%, 240 V
20%, 120 V
0.7
Efficiency
%
80
Current range MIG
A
30-500
Current range TIG
A
30-450
Current range MMA
A
30-450
Open circuit voltage
V
73.6
Filler wire
0.8 1.6mm
Voltage range
V
MIG: 15.5 39
MMA: 21.2 38
TIG: 11.2 28
Wire pool size
mm
300
Wire feed mechanism
4-roll
Duty cycle at 40o C MIG 60%
A
500
Duty cycle at 40o C MIG 100%
A
387
Duty cycle at 40o C TIG/MMA 60%
A
450
Duty cycle at 40o C TIG/MMA 100%
A
349
Recommended generator power (min)
kVA
32
Apparent/Active power
kVA
32
Display
Digital Display
Cooling
Forced Air Cooling
Dimensions
L x W x H (mm)
620 x 295 x 570
Weight
kg
40.5
