K2
MIG 400
Connection voltage
3~phase
400V
Operating temperature
-10-+40 oC
Fuse
32A
Power factor at max current
0.7
Efficiency
80%
Current range MIG
30-500A
Current range TIG
A
30-450
Current range MMA
A
30-450
Open circuit voltage
V
73.6
Filler wire
mm
0.8 1.6
Voltage range
V
MIG: 15.5V-34V
MMA: 21.2V-34V
TIG: 25V-19.4V
Wire pool size
mm
300
Wire feed mechanism
4-roll
Duty cycle at 40o C MIG / 40C
A
60% 400A
100% 310A
Duty cycle at 40o C MMA/TIG 40C
A
450
A
100% 271A
Recommended generator power (min)
kVA
30 kVA
Apparent/Active power
kVA
32 kVA
Display
Digital Display
Cooling
Forced Air Cooling
Dimensions
L x W x H (mm)
620 x 295 x 570
Weight
kg
39
